Description

HCB 1002 Specifications

Capacity
1000g
Readability
0.01g
Repeatability
0.01g
Weighing Units
g, lb, oz, N, GN, ct, dr, dwt, mm, ozt, T, tl.H, tl.S, tl.T
Calibration
External calibration / Internal manual calibration
00 Nav Number
700000048
Stabilisation Time
2.0
Pan Size
120mm ø
Linearity
0.02g
Power Supply
12VDC 50/60Hz 800mA adapter / Internal rechargeable battery
Construction
ABS plastic
Interface
RS-232, USB
Operating Temperature
0° to 40°C
Net Weight
2kg
Dimensions Overall
174x252x80mm (wxdxh)
Electrical Safety Mark
CE, cUL
Display Digit Height
18mm
Battery Life
24.0

Features and Benefits

Hardware

  • Balances stack efficiently and safely to save space (120mm pan size only)
  • Colour-coded keys facilitate quick recognition of the most frequently used buttons
  • Dual tare keys operate with either the left or right hand
  • Level indicator and adjustable feet ensure proper balance setup for optimum weighing results
  • Security slot for optional Kensington-type lock and cable to help prevent theft
  • Large, grade 304 stainless steel pan allows easy cleaning
  • Solid ABS housing is durable for industrial use
  • Three-point ShockProtect feature helps prevent overload damage to internal components
  • Hook included for weighing below the balance
  • HandiCal internal calibration eliminates need for external weight set
  • USB and RS-232 interfaces provide speedy communication with computers and printers

Software

  • Audible overload alarm warns when capacity is exceeded
  • External calibration allows for verification and adjustment with weights
  • Selectable digital filtering helps minimise effects of vibration and disturbances
  • Parts counting with preset sample sizes
  • Memory accumulation totals results
  • Zero-tracking feature ensures display returns to zero reading

Display

  • Vivid, backlit LCD easily visible in any lighting conditions
  • Programmable backlight can be set to “always on,” “always off” or “light only when weighing”
  • Capacity tracker built into display for easily monitoring possible overloads

Power

  • AC adapter included
  • Rechargeable battery included for operation almost anywhere
  • Programmable auto power-off to save energy

Downloads

Applications

  • AccumulationAccumulation
  • Parts countingParts counting
  • Percentage weighingPercentage weighing
  • WeighingWeighing
Technical Highlights

  • Backlit displayBacklit display
  • Internal rechargeable batteryInternal rechargeable battery
  • Below balance weighingBelow balance weighing
  • External calibrationExternal calibration
  • Internal calibrationInternal calibration
  • RS-232RS-232
  • Security lock downSecurity lock down
  • Tare FunctionTare Function
  • USBUSB
